Molicel INR21700 P42A 3.6V 4200mAh 45A Battery | High-Drain Li-ion Cell

MOLICEL INR-21700-P42A Lithium-Ion Cell

Name: MOLICEL INR-21700-P42A Lithium-Ion Cell
SKU: BAT-MCL-4
Availability: OutOfStock

Original price was: ₹550.00.Current price is: ₹456.00. including GST

Out of stock

SKU: BAT-MCL-4 Category: Li - ion Battery Brand: MOLICEL

Model No – INR-21700-P42A
HSN Code – 85076000
Click here to download – Datasheet ⬇️

CELL CHARACTERISTICS

Capacity
- Typical = 4200 mAh 15.5 Wh
- Minimum = 4000 mAh 14.7 Wh
Cell Voltage
- Nominal = 3.6 V
- Charge = 4.2 V
- Discharge = 2.5 V
Charge Current
- Standard = 4.2 A
Charge Time = Standard 1.5 hr
Discharge Current = Continuous 45 A
Typical Impedance
- AC (1 KHz) = 10 mΩ
- DC (10A/1s) = 16 mΩ
Ambient Temperature
- Charge = 0°C to 45°C
- Discharge = -40°C to 60°C
Energy Density
- Volumetric = 615 Wh/l
- Gravimetric = 230 Wh/kg

Tech Summary

Discover unmatched performance with the MOLICEL INR-21700-P42A 3.6V 4200mAh. With a typical capacity of 4200 mAh and nominal voltage of 3.6V, this cell delivers reliable power for your high-drain devices. Its robust discharge current of 45A ensures sustained performance, while the standard charge current of 4.2A provides a full charge in just 1.5 hours. Engineered with typical impedance values of 10 mΩ (AC) and 16 mΩ (DC), this cell guarantees efficiency and stability. Shop this high-quality battery, along with our extensive range of top-notch cells and batteries, and power your needs with confidence
